Switch
Router
CompFi 6
AC3000 Tri-band Cable-Free WiFi Router
- 3000Mbps 11AC Wave 2 WiFi
- 1733Mbps independent Backhaul
- 4*Gigabit Ethernet Port，Max 3*WAN
- A capacity of 200 wireless clients with video playing
- Built-in RF optimization and QoS policy
- Support intelligent bandwidth control, fast roaming, seamless roaming
- Support non-standard PoE module power supply
- Support wall mount/desktop installation
iUAP-AC-LITE
Overview
The IEEE 802.11ac Wave 2-compliant iUAP-AC-LITE is a gigabit dual-band ceiling access point. It offers a concurrent data rate as high as of 1167 Mbps. Powered by MU-MIMO technology, a single iUAP-AC-LITE can simultaneously communicate with multiple clients, greatly improving the throughput and bettering user experience. The built-in omni-directional antennas optimize signal radiating directions, broadening the wireless coverage of a single AP. iUAP-AC-LITE can be powered by PoE sourcing equipment that compliant with IEEE 802.3af/at. With its ceiling installation design and sleek appearance, it simplifies wireless networking for enterprises, hotels and other public indoor spaces.
Gigabit internet connections for ultra-fast experience
Up to 1167 Mbps dual-band data rate, and the Gigabit Ethernet port offers you ultra-fast internet connections.
IEEE 802.11ac Wave 2 and MU-MIMO
Compliant with IEEE 802.11ac Wave 2 and powered by MU-MIMO technology, a single iUAP-AC-LITE can communicate with multiple wireless clients simultaneously, leading to higher throughput.
2.4 GHz and 5 GHz bands for more connected clients
The dual-band wireless design allows clients that support 2.4 GHz and/or 5 GHz bands to connect to the AP at the same time, tripling the quantity of connected clients of traditional single-band AP.
Built-in omni-directional antennas
With the optimized built-in high-gain omni-directional antennas, iUAP-AC-LITE outperforms in radiating wireless signals, and greatly broadens its wireless coverage.
Built-in RF optimization
iUAP-AC-LITE supports RF optimization technology and integrates with various algorithms for interference mitigation. Features include multi-user fairness, interference filtering, speed optimization, and signal strength guarantee.
VLAN tagging for SSID
iUAP-AC-LITE allows you to set multiple SSIDs, and the IEEE 802.11q VLAN-compliant feature enables you to add VLAN tags for SSIDs, thus protecting the security of your network.
Standard PoE sourcing and DC power supply for easy deployment
iUAP-AC-LITE can be powered by PoE sourcing equipment that compliant with IEEE 802.3af/at and 24V0.5A Passive PoE
Centralized management
The ProFi Controller makes it easy to manage and monitor the whole ProFi devices in a real-time manner and cloud services enable a remote and secure access free from the restrictions of device location.
SPECIFICATIONS
| Product Information | |
|---|---|
| Model | iUAP-AC-LITE |
| Appearance | Ceiling |
| Dimensions | 176*176*43.5mm |
| Hardware Specifications | |
| Frequency band | 2.4 GHz, 5 GHz |
| Wireless standards | IEEE 802.11a, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac |
| 2.4 GHz data rate | 1 – 300 Mbps |
| 5 GHz data rate | 6 – 867 Mbps |
| Ethernet port | 1*10/100/1000 Base-TX port |
| Button | 1*Reset |
| LED indicator | 1*Power |
| Max. power consumption | Full-load 11.5W |
| Power supply standard | IEEE 802.3af/at&24V0.5A Passive PoE |
| Antenna gain | 2*4 dBi |
| 2.4 GHz Max. output power | 23+/- 1.5 dBm |
| 5 GHz Max. output power | 23 +/-1.5 dBm |
| 802.11b RX sensitivity | -93 dBm |
| 2.4 GHz 802.11n (MCS7) RX sensitivity | -72 dBm |
| 5 GHz 802.11a RX sensitivity | -93 dBm |
| 5 GHz 802.11n (MCS7) RX sensitivity | -74 dBm |
| Software Specification | |
| Operating modes | AP, Client + AP |
| Hide SSID | Supported |
| Max. No. of SSID | 2.4 GHz:8 5 GHz:4 |
| Max. connected clients | 2.4 GHz:128 5 GHz:128 |
| WEP | Supported |
| WPA-PSK | AES/TKIP |
| WPA2-PSK | AES/TKIP |
| WPA | Supported |
| WPA2 | Supported |
| Access control | MAC address-based |
| Adjustable power transmit | Supported |
| Frequency analysis | Supported |
| 802.11 k/v/r | Supported |
| AP isolation | Supported |
| Connected clients control | Supported |
| RSSI threshold | Supported |
| Transmission Power | Adjustable power by 1dBm |
| WMM | Supported |
| VLAN tagging for SSID | Supported |
| LED indicator control | Supported |
| Diagnostics tool | Ping, Traceroute |
| Scheduled reboot | Supported |
| Reboot at specified interval | Supported |
| Management | Web UI |
| System logs | Supported |
| Firmware upgrade | Local and AC upgrade |
| Reboot | Local and AC reboot |
| Reset | Local and AC reset |
| Backup configuration | Supported |
| Restore configuration | Supported |
| Operating Environment | |
| Default login IP address | 192.168.0.254 |
| Default user name | admin |
| Default password | admin |
| Operating temperature | -10℃ – 45℃ |
| Operating humidity | (10%-90%) RH, non-condensing |
| Storage temperature | -30℃ – 70℃ |
| Storage humidity | (10%-90%) RH, non-condensing |
