F1106P-4-63W

SKU: F1106P-4-63W

6-Port 10/100M Unmanaged Switch With 4-Port PoE

  • Compliant with IEEE 802.3, IEEE 802.3u, IEEE 802.3x and IEEE802.3af/at standards
  • 4*10/100 Mbps Base-TX RJ45 ports for data transmission and power supply
  • 2*10/100 Mbps Base-TX RJ45 ports for data transmission
  • 1 K MAC address table and MAC address auto-learning
  • IEEE 802.3x-compliant full-duplex flow control and half-duplex backpressure flow control
  • 1.2 Gbps backplane bandwidth
  • Maximum power consumption of a single port:30W
  • Maximum power consumption of the switch: 58W
  • Supports extend mode and QoS function
  • Supports desktop and wall-mounting, plug and play

40,00 €

Add to wishlist
Add to compare
15 People watching this product now!

Fast Shipping

Carrier information

Best quality products

Only best

24/7 Support

Unlimited help desk

2-day Delivery

Track or off orders

Description

F1106P-4-63W    Overview

F1106P-4-63W is an unmanaged PoE switch with 2 uplink ports, independently designed by IP-COM. Compliant with IEEE 802.3at/af standards, it can identify PoE-powered devices intelligently. The switch supplies a maximum PoE power output of 63 W, and 30 W for a single port. Featured with extend mode and QoS function, F1106P-4-63W is a ideal choice for SMBs, supermarkets and restaurants with small-sized video surveillance requirement.

6 kV lightenning protection

The switch offers various safety and protection types, including 6 kV lightning protection, PSE short-circuit protection, PoE overload protection, surge current protection etc.

Dual uplink port

With two 10/100 Mbps uplink ports, the switch can meet the current demand for uplink bandwidth with NVR and router connection.

Standard PoE power supply

The switch features 4 IEEE 802.3at/af-compliant RJ45 ports. The entire switch offers a maximum PoE power output of 58 W, and 30 W for a single port, to supply power to and data transmission with IP cameras.

Ethernet extend mode

It supports extend mode. The hardware DIP mode switch makes long distance transmission effortless.



SPECIFICATIONS



Product model F1106P-4-63W
Hardware features
Standard&Protocol IEEE 802.3/IEEE 802.3u/IEEE 802.3x/IEEE 802.3af/IEEE 802.3at
Indicator 6 * Link/Ack LED indicators
1 * Power LED indicator
Interface 4 * 10/100 Mbps Base-TX RJ45 ports (Data/Power)
2 * 10/100 Mbps Base-TX RJ45 ports (Data)
Port Lightning Protection 6KV for uplink port
Store and forward Yes
Exchange Capacity 1.2 Gbps
Packet forwarding rate 1.34Mpps
MAC Address Table 1K
PoE supply management Port 1-4 support IEEE802.3at/af PoE standard
PoE through pin 1 2 4 5 +;3 6 7 8 –
Voltage input range AC: 100-240V～50/60Hz DC: 51V 1.25A
Dimensions ( W x D x H ) 100*100*26mm
Power Consumption In full configuration: 63W
PoE Max Power Supply: 58W
Function One-key to change network mode:
1.Standard: the switch functions as a common unmanaged switch and all the ports of the switch can communicate with each other.
2.Extend Mode: If Extend mode is enabled, Port 1-4 will be isolated respectively (10Mbps auto-negotiation).And the delivery distance of powering and network data is up to 250m (10Mbps).
Environment Operating Temperature: 0℃~40℃(32℉~104℉)
Storage Temperature: -40℃~70℃(-40℉~158℉)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing
